Bellari VP530 Tube Phono Stage with USB & Analog Outputs (Black)
Bellari VP530 Tube Phono Stage with USB & Analog Outputs (Black) Bellari VP530 Tube Phono Stage with USB & Analog Outputs (Black) Bellari VP530 Tube Phono Stage with USB & Analog Outputs (Black) Bellari VP530 Tube Phono Stage with USB & Analog Outputs (Black)

Share:

Bellari VP530 Tube Phono Stage with USB & Analog Outputs (Black)

$398.99



Availability: In Stock
In Stock An In Stock item is available to ship normally within 24 business hours.
Preorder A Preorder is an item that has not yet been released. Typically the label will set a projected release date (that is subject to change). If a projected release date is known, we will include this in the description in red. Other Preorders are set to release "TBA." This means that release date is yet "To Be Announced". The Preorder can be released anywhere between weeks, months or years from its initial announcement.
Out of Stock An Out Of Stock item is an item that we normally have available to ship but we are temporarily out of.
Awaiting Repress Awaiting repress titles are in the process of being repressed by the label. No ETA is available at this time.
Expected On When an item is Out Of Stock and we have an estimated date when our stock should arrive, we list that date on our website in the part's description.
Special Order A Special Order item is an item that we do not stock but can order from the manufacturer. Typical order times are located within the product description.
SKU:
MHVP530B
UPC:
675889053005
The Bellari VP530 is the Big Brother to the Stereophile Class B recommended component VP129 Tube Phono Stage!

The Bellari VP530 Phonostage is the improved version of the Stereophile Class B Recommended VP129 Tube Phonostage! The VP530 builds upon the basic circuit built into the Bellari VP129. The VP530 Phono Stage features a switch to turn off the RIAA (phono) circuitry so you can feed it either a turntable or a high level source such as a reel to reel or cassette deck.

Imagine running along the beach listening to your favorite records. Well...Wally it's no longer pure fantasy! We all know the sweet luscious sounds produced by the highly acclaimed Bellari VP129. Now, Bellari have released a USB version of the VP129 named the VP530. Going one better than VP129, the VP530 has a USB output which allows users to download their vinyl collection to their computer or hard disc server.

The VP530 employs a sophisticated Burr-Brown PCM2901EG (16 bit 44.1khz) chip in a smartly designed Bellari circuit. This gives you a digital datastream that is output through USB. Through the use of audio editing and recording software you can record this datastream to your hard disc. Audio recording software is included with the VP530 but we recommend the freeware Audacity:

www.audacity.sourceforge.net

To RIAA or not to RIAA? That is the question. If you're like Randy..."I want to set my own curve"...Audio Vision SF the answer is dead flat...sans RIAA. You can output a flat datastream and set whatever curve you like. You can also choose your own sampling rate and format. Hell...you can start cutting up the tracks sampling and make your own damn music.

The VP530 is a USB/Tube Phono Stage for use with moving-magnet and high output moving-coil cartridges. It includes a built in headphone amplifier, Burr-Brown A2D converter w/USB output, and RIAA curve/flat EQ. The VP530 is designed to amplify an RIAA equalized phono signal to a hi-level signal or provide a usb digital output. Since the unit utilizes tube circuitry, the resulting output signal is more warm and musical than solid state preamplifiers. The real kicker aside from the price and stellar sound is that it's manufactured in the US.

Features:
• Universal Input 90V-240V AC, 47-63Hz
• RIAA/Flat Equalization
• All tube circuitry
• Switchable Rumble Filter
• Mute Switch
• Headphone Output w/variable level control
• 1/8" and 1/4" Headphone jacks
• Steel Chassis

Specifications:
• Power Supply: Universal Input 90V-240V AC, 47-63Hz
• I/ O Connectors: RCA,1/4" TRS Stereo, mini USB
• Input Sensitivity: 30 dB gain @ 1kHz, 47k ohms
• Input Impedance: 50k ohms
• Output Impedance: 8 ohms Headphone, 100 ohms RCA
• Max Output Level: Greater Than 10dB @ 1kHz at .1% dist.
• Equalization: RIAA +/- 1.5 dB, 20Hz to 20kHz
• Burr-Brown PCM2901EG, 16 bit 44.1khz
• Rumble Filter: 20Hz
• THD: .02% @ 1KHz
• S/N Ratio: Greater than 80 dB unweighted
• PWR: PSU115 15 V DC 700Ma
• Size: 6"W x 2.5"H x 5.4"D
• Weight: 2 lb
• Indicator: 1 Power LED

Click Here for the Bellari VP530 Tube Phono Stage manual!
Description
The Bellari VP530 is the Big Brother to the Stereophile Class B recommended component VP129 Tube Phono Stage!

The Bellari VP530 Phonostage is the improved version of the Stereophile Class B Recommended VP129 Tube Phonostage! The VP530 builds upon the basic circuit built into the Bellari VP129. The VP530 Phono Stage features a switch to turn off the RIAA (phono) circuitry so you can feed it either a turntable or a high level source such as a reel to reel or cassette deck.

Imagine running along the beach listening to your favorite records. Well...Wally it's no longer pure fantasy! We all know the sweet luscious sounds produced by the highly acclaimed Bellari VP129. Now, Bellari have released a USB version of the VP129 named the VP530. Going one better than VP129, the VP530 has a USB output which allows users to download their vinyl collection to their computer or hard disc server.

The VP530 employs a sophisticated Burr-Brown PCM2901EG (16 bit 44.1khz) chip in a smartly designed Bellari circuit. This gives you a digital datastream that is output through USB. Through the use of audio editing and recording software you can record this datastream to your hard disc. Audio recording software is included with the VP530 but we recommend the freeware Audacity:

www.audacity.sourceforge.net

To RIAA or not to RIAA? That is the question. If you're like Randy..."I want to set my own curve"...Audio Vision SF the answer is dead flat...sans RIAA. You can output a flat datastream and set whatever curve you like. You can also choose your own sampling rate and format. Hell...you can start cutting up the tracks sampling and make your own damn music.

The VP530 is a USB/Tube Phono Stage for use with moving-magnet and high output moving-coil cartridges. It includes a built in headphone amplifier, Burr-Brown A2D converter w/USB output, and RIAA curve/flat EQ. The VP530 is designed to amplify an RIAA equalized phono signal to a hi-level signal or provide a usb digital output. Since the unit utilizes tube circuitry, the resulting output signal is more warm and musical than solid state preamplifiers. The real kicker aside from the price and stellar sound is that it's manufactured in the US.

Features:
• Universal Input 90V-240V AC, 47-63Hz
• RIAA/Flat Equalization
• All tube circuitry
• Switchable Rumble Filter
• Mute Switch
• Headphone Output w/variable level control
• 1/8" and 1/4" Headphone jacks
• Steel Chassis

Specifications:
• Power Supply: Universal Input 90V-240V AC, 47-63Hz
• I/ O Connectors: RCA,1/4" TRS Stereo, mini USB
• Input Sensitivity: 30 dB gain @ 1kHz, 47k ohms
• Input Impedance: 50k ohms
• Output Impedance: 8 ohms Headphone, 100 ohms RCA
• Max Output Level: Greater Than 10dB @ 1kHz at .1% dist.
• Equalization: RIAA +/- 1.5 dB, 20Hz to 20kHz
• Burr-Brown PCM2901EG, 16 bit 44.1khz
• Rumble Filter: 20Hz
• THD: .02% @ 1KHz
• S/N Ratio: Greater than 80 dB unweighted
• PWR: PSU115 15 V DC 700Ma
• Size: 6"W x 2.5"H x 5.4"D
• Weight: 2 lb
• Indicator: 1 Power LED

Click Here for the Bellari VP530 Tube Phono Stage manual!
