Brand: Music Hall

Share:

Music Hall MMF-2.3WH Turntable (White) with Spirit MM Cartridge 3.5mV

$548.99

Availability: Discontinued
In Stock An In Stock item is available to ship normally within 24 business hours.
Preorder A Preorder is an item that has not yet been released. Typically the label will set a projected release date (that is subject to change). If a projected release date is known, we will include this in the description in red. Other Preorders are set to release 'TBA.' This means that release date is yet 'To Be Announced'. The Preorder can be released anywhere between weeks, months or years from its initial announcement.
Backordered An Out Of Stock item is an item that we normally have available to ship but we are temporarily out of. We do not have a specific date when it will be coming.
Awaiting Repress Awaiting repress titles are in the process of being repressed by the label. No ETA is available at this time.
Expected On When an item is Out Of Stock and we have an estimated date when our stock should arrive, we list that date on our website in the part's description. It is not guaranteed.
Special Order A Special Order item is an item that we do not stock but can order from the manufacturer. Typical order times are located within the product description.

SKU:
MMF-23WH
UPC:
MMF-23WH
The New & Improved version of the Award Winning MMF-2.2 is here! Music Hall's MMF-2.3 Turntable features a gorgeous high gloss white finish, special vibration damping adjustable feet, carbon fiber tonearm & Music Hall Spirit MM Cartridge!

The Music Hall MMF-2.3 is a 2-speed belt driven audiophile turntable at a budget price! Constructed using high quality components, the Music Hall MMF-2.3 comes complete with a carbon fiber tonearm, mounted Music Hall Spirit MM Cartridge and removable Dust Cover!

The Music Hall MMF-2.3 is constructed using high quality components and it comes complete with a tonearm and cartridge mounted. The construction of the mmf-2.3 has been simplified to focus on the critical components: the bearing, the motor, and the tonearm.

Features:
• Gorgeous high gloss white lacquer finish
• Special vibration damping adjustable feet
• Top tier 8.6" carbon fiber tonearm with aluminum headshell
• Low noise fully manual belt-drive design
• Separately isolated DC synchronous motor for superior speed stability
• Two-speed stepped motor pulley for 33 1/3 and 45 rpm
• Music hall Spirit moving-magnet cartridge with replaceable elliptical stylus ($100 value)
• The cartridge supplied is properly aligned and mounted
• High precision stainless steel and bronze bearing assembly for quiet fluid operation
• High quality gold RCA connectors with detachable phono cable
• Full-size alloy platter and felt mat
• Excellent instruction manual
• Quick and easy to assemble
• Dust Cover and 45 rpm adaptor

Music Hall MMF-2.3 Turntable Specifications:
Power Supply: 15V / 0-0.8mA DC universal power supply
Power Connection: 110/120 or 230/240 Volt, 50 or 60 Hz
Standby Power Consumption: Less Than 1 W
Speeds: 33 1/3 rpm (manual change to 45 rpm)
Wow and Flutter: +/- 0.10 %
Speed Deviation: +/- 0.80%
Rumble Max: Greater Than – 68 db
Effective Tonearm Length: 8.6 in. (218.5 mm)
Effective Arm Mass: 7.0 g
Overhang: 18.5 mm
Table Dimensions: W17 x D13 x H4.5 in.
Table Weight: 17lbs. pkg.

Includes: 1 year manufacturer warranty.

Music Hall Spirit MM Cartridge Specifications:
Frequency Response: 20Hz–20kHz +/-3dB
Channel Balance: 2.5dB @ 1kHz
Channel Separation: Greater Than 20dB @ 1kHz
Output: 3.5mV +/-2dB, 1kHz @ 5cm/sec
Vertical Tracking Angle: 20 degrees
Stylus Shape: Elliptical 0.4 x 0.7 mil
Stylus Type: Replaceable
Cantilever: Alloy tube
Load Impedance: 47,000 Ohm
Stylus Construction: Bonded Round Shank
Cartridge Weight: 5.7g
Fixing Center: 0.5" (12.7mm)
Playing Weight 1.5–2.5g (2.0g nom.)

Click Here for the Music Hall MMF-2.3 Turntable Manual!
