Get your groove on with Music Hall's 'Plug-n-Play' US-1 Turntable!
The Music Hall US-1 comes with the AT3600L MM Cartridge professionally installed at the factory!
This item not eligible for any further discount offers!
Music Hall's US-1 Turntable with Audio Technica AT3600L MM Cartridge is a convenient, easy to use, and fun turntable. It's a snap to set up and comes with everything you need to start spinning vinyl.
Whether you're looking to release your inner DJ, or simply discover the joy of spinning vinyl, the US-1 is your answer. The US-1 has a built-in phono preamp, cartridge, dust cover, and includes all necessary cables and software required for simple plug and play operation.
- Extremely quiet belt drive, 2-speed turntable
- Aluminum die-cast platter
- 33 1/3 and 45 rpm playback speeds
- High gloss black finish
- Built-in phono amp or direct line out
- Static balanced S-shaped tonearm w/detachable headshell
- Audio Technica AT3600L moving-magnet cartridge supplied
- Anti-skating control for increased stereo balance
- +/- 10% adjustable pitch control
- Dust cover included
- Designed and developed in the US and France
- w17.7 x d13.8 x h5.7 in.
- 12 lbs. pkg.
- Includes: 1 year manufacturer warranty
|Model:||US-1, Professional Belt Drive Turntable|
|Dimensions||450(W) x 350(D) x145 (H) mm|
|Power Supply:||Dual Voltage: AC 115V~60Hz/230V~50Hz, User Selectable|
|Standard Test Condition:||Ambient Temperature: 23+/- 2 Degrees C|
|Relative Humidity:||65% +/- 5%|
|Type||2-Speed Full Manual|
|Driving Method||Belt Drive|
|Turntable Platter||330mm dia. Aluminum|
|Speeds||33 1/3 and 45rpm|
|Wow and Flutter||Less than 0.25% WRMS (JIS WTD) with 33 1/3 rpm|
|S/N Ratio||More Than 50dB (DIN-B)|
|Pitch Controls||+/- 10%|
|Starting Time||Less than 1 sec. with 33 1/3 rpm|
|Braking Time||Less than 1 sec. with 33 1/3 rpm|
|Time for Speed Change||Less than 1 sec. from 33 1/3 to 45 rpm / Less than 1 sec. from 45 to 33 1/3 rpm|
|Speed tolerance at pitch=0||Within +/-1.3%|
|Type||Static balanced S-shaped tonearm with detachable headshell|
|Effective Arm Length||220 mm|
|Tracking Error Angle||Less than 3 degree|
|Applicable Cartridge Weight||6~10g|
|Phono Output Level||1.5~3.6 mV at 1KHz 5cm/sec (HP-4005)|
|Line Output Level||90~216mV at 1KHz 5cm/sec (HP-4005)|
|Channel Separation||More than 15dB|
|Channel Balance||Within 2.5dB at 1KHz|
|Needle Pressure range||3~4g|
|High of cue (first track)||6~10.5mm|
|Descend of cue||1~3 sec|
|Output||150mV +/-4dB (IN: 2.5 mV 1KHz)|
|RIAA||20Hz~20KHz +1/-3dB (IN: 1.5 mV 1KHz)|
Audio Technica AT3600L MM Cartridge Specifications
|Output||4.2mV at 5cm/sec|
|Tracking Force||1.5-3.0 grams|
|Stylus||0.6 mil conical diamond tip|
