Musical Fidelity M8 Encore 500 Streaming Music System (Black)
Musical Fidelity M8 Encore 500 Streaming Music System (Black) Musical Fidelity M8 Encore 500 Streaming Music System (Black)

Share:

Musical Fidelity M8 Encore 500 Streaming Music System (Black)

$7,998.99



Availability: Special Order
In Stock An In Stock item is available to ship normally within 24 business hours.
Preorder A Preorder is an item that has not yet been released. Typically the label will set a projected release date (that is subject to change). If a projected release date is known, we will include this in the description in red. Other Preorders are set to release "TBA." This means that release date is yet "To Be Announced". The Preorder can be released anywhere between weeks, months or years from its initial announcement.
Out of Stock An Out Of Stock item is an item that we normally have available to ship but we are temporarily out of.
Awaiting Repress Awaiting repress titles are in the process of being repressed by the label. No ETA is available at this time.
Expected On When an item is Out Of Stock and we have an estimated date when our stock should arrive, we list that date on our website in the part's description.
Special Order A Special Order item is an item that we do not stock but can order from the manufacturer. Typical order times are located within the product description.
SKU:
MUFNPM8EN500B
UPC:
MUFNPM8EN500B

Typically ready to ship in 2-4 weeks.

The Encore 500 is a complete audio solution allowing you to keep all your music in one place. It accepts almost any conceivable analog or digital audio source. It is also compatible with many network speakers, such as Sonos. There is a very clear, large, high resolution full color display so you can see what’s going on.

The Encore is easy and intuitive to use. It has 500 watts per channel and a huge range of facilities; 3 analog inputs, 4 digital inputs, 4 USB A connections (one of which has high current capacity for charging phones and tablets), network connectivity, high quality variable line level outputs as well as a digital output.

The Encore 500 has an built-in CD player and a 2TB hard disk drive for storage - enough for over 5000 CDs. The heart of the Encore is a powerful dual core 64 bit Intel CPU with 2GB of RAM. This provides superb performance and allows continual upgrading of its facilities making the Encore virtually future proof.

Features
  • Easy and intuitive to use
  • Huge connectivity
  • Standard 2TB internal storage for over 5000 CDs
  • Compatible with many network speakers, such as Sonos
  • Large, high resolution, full colour display
  • Control with either IR handset or Apps (both Apple & Android)
  • Dual core 64bit Intel CPU - as future proof as Musical Fidelity can make it
  • 32 Bit 384k DAC
  • Spotify, Tidal & Qobuz Streaming Services
  • NAS Drive Compatible
  • New Bridged amplifier arrangement based on those in the M6 Encore 225

Technical Specifications

Output performance
  • Power 500 Watts per channel into 8 Ohms
  • Voltage 63Volts RMS, 20Hz to 20 kHz; onset of clipping
  • 178 Volts peak to peak
  • Current 90 Amps peak to peak
  • Damping factor 180
  • Output devices 4 pairs per channel
Line input performance
  • Input signal voltage 0-7 Vrms maximum
  • THD+N < 0.007 % typical, 20Hz to 20 kHz
  • Signal / noise ratio > 107dB ‘A’-weighted
  • Input impedance 40 kOhm
  • Frequency response + 0, –0.1dB, 10Hz to 20 kHz
Line level inputs
  • 3 pairs line level RCA connectors
  • Digital inputs
  • 2 Optical S/PDIF (up to 24bit/192kHz)
  • 2 Coaxial S/PDIF (up to 24bit/192kHz)
USB sockets
  • 1 Front panel Type A USB2 socket (1.5A USB-BC 1.2 compliant)
  • 2 Back panel Type A USB2 socket (500mA)
  • 1 Back panel Type A USB3 Socket (USB-BC1.2)
  • 1 Back panel Type B socket (Factory use only)
  • 1 pair line level RCA connectors, fixed level outputs gain = 0dB (x1) 7 Vrms output maximum
  • 1 pair line level RCA connectors, PREAMP outputs set by volume gain = -8 to +13dB maximum 7 Vrms output maximum
Digital Outputs
  • 1 Optical S/PDIF (up to 24bit/192kHz)
  • 1 Coaxial S/PDIF (up to 24bit/192kHz)
  • Speaker outputs
  • 2 pairs 4mm banana plug/binding posts (1 set each left and right)
Headphone outputs
  • 0.25” (6.35mm) impedance 10Ohm - 8
Network connection
  • RJ45 8P8C 10/100/1000Base-T
Power requirement
  • Mains voltages 115/230VAC 50/60Hz (factory pre-set)
  • 100VAC 50/60Hz (alternative)
Power Consumption
  • <0.5W in standby mode
  • 58W idle
  • 1.6k Watts maximum
Weight
  • Unit only, unboxed 38.5 kg (84 lbs)
  • In shipping carton (inc. accessories) 47 kg (103 lbs)
Dimensions
  • Wide 483 mm (19”)
  • High, including feet 185 mm (7 1/3 ”)
  • Deep (front to back) including terminals 510 mm (20”)
Standard accessories
  • IEC type mains lead 16-Amp type
  • Remote control
  • Batteries LR03 or AAA, manganese alkaline type 2 off
  • Ethernet cable
  • Quick start guide

5 Year Warranty

Description

Typically ready to ship in 2-4 weeks.

The Encore 500 is a complete audio solution allowing you to keep all your music in one place. It accepts almost any conceivable analog or digital audio source. It is also compatible with many network speakers, such as Sonos. There is a very clear, large, high resolution full color display so you can see what’s going on.

The Encore is easy and intuitive to use. It has 500 watts per channel and a huge range of facilities; 3 analog inputs, 4 digital inputs, 4 USB A connections (one of which has high current capacity for charging phones and tablets), network connectivity, high quality variable line level outputs as well as a digital output.

The Encore 500 has an built-in CD player and a 2TB hard disk drive for storage - enough for over 5000 CDs. The heart of the Encore is a powerful dual core 64 bit Intel CPU with 2GB of RAM. This provides superb performance and allows continual upgrading of its facilities making the Encore virtually future proof.

Features
  • Easy and intuitive to use
  • Huge connectivity
  • Standard 2TB internal storage for over 5000 CDs
  • Compatible with many network speakers, such as Sonos
  • Large, high resolution, full colour display
  • Control with either IR handset or Apps (both Apple & Android)
  • Dual core 64bit Intel CPU - as future proof as Musical Fidelity can make it
  • 32 Bit 384k DAC
  • Spotify, Tidal & Qobuz Streaming Services
  • NAS Drive Compatible
  • New Bridged amplifier arrangement based on those in the M6 Encore 225

Technical Specifications

Output performance
  • Power 500 Watts per channel into 8 Ohms
  • Voltage 63Volts RMS, 20Hz to 20 kHz; onset of clipping
  • 178 Volts peak to peak
  • Current 90 Amps peak to peak
  • Damping factor 180
  • Output devices 4 pairs per channel
Line input performance
  • Input signal voltage 0-7 Vrms maximum
  • THD+N < 0.007 % typical, 20Hz to 20 kHz
  • Signal / noise ratio > 107dB ‘A’-weighted
  • Input impedance 40 kOhm
  • Frequency response + 0, –0.1dB, 10Hz to 20 kHz
Line level inputs
  • 3 pairs line level RCA connectors
  • Digital inputs
  • 2 Optical S/PDIF (up to 24bit/192kHz)
  • 2 Coaxial S/PDIF (up to 24bit/192kHz)
USB sockets
  • 1 Front panel Type A USB2 socket (1.5A USB-BC 1.2 compliant)
  • 2 Back panel Type A USB2 socket (500mA)
  • 1 Back panel Type A USB3 Socket (USB-BC1.2)
  • 1 Back panel Type B socket (Factory use only)
  • 1 pair line level RCA connectors, fixed level outputs gain = 0dB (x1) 7 Vrms output maximum
  • 1 pair line level RCA connectors, PREAMP outputs set by volume gain = -8 to +13dB maximum 7 Vrms output maximum
Digital Outputs
  • 1 Optical S/PDIF (up to 24bit/192kHz)
  • 1 Coaxial S/PDIF (up to 24bit/192kHz)
  • Speaker outputs
  • 2 pairs 4mm banana plug/binding posts (1 set each left and right)
Headphone outputs
  • 0.25” (6.35mm) impedance 10Ohm - 8
Network connection
  • RJ45 8P8C 10/100/1000Base-T
Power requirement
  • Mains voltages 115/230VAC 50/60Hz (factory pre-set)
  • 100VAC 50/60Hz (alternative)
Power Consumption
  • <0.5W in standby mode
  • 58W idle
  • 1.6k Watts maximum
Weight
  • Unit only, unboxed 38.5 kg (84 lbs)
  • In shipping carton (inc. accessories) 47 kg (103 lbs)
Dimensions
  • Wide 483 mm (19”)
  • High, including feet 185 mm (7 1/3 ”)
  • Deep (front to back) including terminals 510 mm (20”)
Standard accessories
  • IEC type mains lead 16-Amp type
  • Remote control
  • Batteries LR03 or AAA, manganese alkaline type 2 off
  • Ethernet cable
  • Quick start guide

5 Year Warranty
