Nothing demonstrates Ortofon's long-standing resilience more than its commitment to the refinement of analogue sound quality and its continued development of new cartridge models. Since 1948 Ortofon has introduced about 100 different Moving Coil models. We believe the cartridges in this new series are more than worthy successors to the long line of models that has made Ortofon the global leader in the manufacture and supply of phono cartridges.
The MC Quintet Series is congruent with Ortofons unrelenting commitment to providing the most precise and accurate reproduction possible without coloration:
A special ABS (Acrylonitrile/Butadiene/Styrene) thermoplastic material is used for manufacturing of the body. This light-weight, impact resistant material is very suitable for injection-moulding and provides a very durable scratch resistant surface.
Neodymium magnets are implemented to achieve an optimal output.
Low internal impedance makes the cartridge less sensitive to load and therefore ensures compatibility with the widest range of preamps and transformers.
It is Ortofon's aim to bring the customer many hours of new and surprising experiences in listening to their precious vinyl collection.
Top-mounting of the Quintet cartridges is easy and secure using the screws supplied. The aluminuim frame has threaded mounting holes and is fitted easily with the 5mm or 7mm screws depending on the thickness of the headshell.
The Quintet series right angles, straight lines, stylus visibility and ample distance between the record surface and the cartridges bottom will make it easy to mount and align the cartridge and tonearm correctly. The Quintet Series gives excellent results with most common tonearms.
"...No matter the sonic extremes I threw its way, the Ortofon Quintet Bronze never lost its buttoned-down composure, reproducing a full frequency range performance every time. It never favored one part of the spectrum over another, its top to bottom smoothness and coherency perhaps its most outstanding and noticeable trademark. This brother is smooth..."
"...The Quintet Bronze presented harmonic textures naturally without drawing attention to itself. But while it definitely creates a first-row presentation of the music, its gentle demeanor places it in the laidback variety of moving coil cartridges. It has more energy and transparency than moving magnet carts Ive used, but its big, round, warm sonic portrayal of events is more buttery and compliant than breath-taking and bold..."
"...At its asking price, the Ortofon Quintet Bronze is reasonably priced, and it's certainly capable of expressing a wide frequency range performance with a large soundstage, natural textures, and spot-on tonality. While the Bronze was in my system I wanted for nothing more, save a better grip on low end fundamentals. The Bronze was never soft and fuzzy, but it tends to roll off upper treble, denying the fine detail that the less expensive Denon, and other moving coil carts, easily convey. If you have a solid state based system, the Ortofon Quintet Bronze cartridge may be the full bodied compliment you've been looking for." - Ken Micallef, Positive Feedback, January 2015, Issue 81
Output voltage at 1000 Hz, 5cm/sec.: 0.3 mV
Channel balance at 1 kHz: < 1.2 dB
Channel separation at 1 kHz: > 23 dB
Channel separation at 15 kHz: > 15 dB
Frequency range at: 3dB: 20-25.000 Hz
Frequency response 20-20.000 Hz: +/-1.5 dB
Tracking ability at 315Hz at recommended tracking force *): 80 µm
Compliance, dynamic, lateral: 15 µm/mN
Stylus type: Nude Fine Line
Stylus tip radius: r/R 8/40 µm
Tracking force range: 2.1-2.5 g (21-25 mN)
Tracking force, recommended: 2.3 g (23 mN)
Tracking angle: 20°
Internal impedance, DC resistance: 5 Ohm
Recommended load impedance: > 20 Ohm
Cartridge body material: ABS/Aluminium
Coil wire material: Pure 4-nines copper
Cartridge colour: Bronze
Cartridge weight: 9 gram
1 Year Warranty
