The Music Hall PA2.2 is the Swiss Army Kife of Phono Amps!
It's an Analog to Digital Converter, Headphone Amp, Pre-Amp & Phono Amp all in one box!
Swiss Army Knife:
The Music Hall PA2.2 is an ultra quiet MM/MC phono amp, a high-grade headphone amp, an analog-to-digital converter, and a high-resolution 2-input pre-amplifier (phono and line level) in one beautiful package.
Unrivaled Versatility:
Fixed or variable line output capability. Record vinyl or any line level source to computer.
Features:
ultra quiet MM/MC phono amp
high-grade headphone amp
high resolution 2 input pre-amp (phono and line level)
record vinyl or any line level source to computer
adjustable MC gain stage
USB digital output
Apple Mac and Windows compatibility
high performance 24bit/96kHz analog to digital converter
superior wolfson WM8786 ADC
tenor TE7022 24bit/96kHz USB receiver
stereo or mono capability – sounds amazing with mono records
phase/invert switch for prefect audio phase
fixed or variable line output capability
high-quality 1/4” headphone output
gold-plated RCA inputs and outputs
silky smooth high-grade Alps “blue velvet” volume control
energy efficient external switch mode power supply
worldwide compatibility
solid alloy construction
vibration damping feet
Specifications:
MM input impedance: 47 kohms + 220 pF
MC input impedance: 100 ohms + 1 pF
Analog line-level input impedance: 47 kohms
MM gain at 1khz: 39 dB
MC gain at 1khz: 59 dB (20 dB gain selected) / 65 dB (26 dB gain selected)
MM input sensitivity for 316 mV output: 3.3 mV
MC input sensitivity for 316 mV output: 0.4 mV (20 dB gain selected) / 0.2 mV (26 dB gain selected)
MM signal-to-noise ratio unweighted (with cartridge connected): 70 dB
MC signal-to-noise ratio unweighted (with cartridge connected): 75 dB (20 dB gain) / 70 dB (26 dB gain)
Analog line-level input signal-to-noise ratio: 120 dB
MM Input overload level at 20Hz/1kHz/20kHz: 8/71/650 mV
MC Input overload level at 20Hz/1kHz/20kHz (20 dB gain selected): 0.95/48/450 mV
MC Input overload level at 20Hz/1kHz/20kHz (26 dB gain selected): 0.45/24/225 mV
