Tri-Art S-Series TA-0.5 Turntable (No Cartridge)
Brand: Tri-Art

Share:

Tri-Art S-Series TA-0.5 Turntable (No Cartridge)

$715.00

Availability: Discontinued
In Stock An In Stock item is available to ship normally within 24 business hours.
Preorder A Preorder is an item that has not yet been released. Typically the label will set a projected release date (that is subject to change). If a projected release date is known, we will include this in the description in red. Other Preorders are set to release 'TBA.' This means that release date is yet 'To Be Announced'. The Preorder can be released anywhere between weeks, months or years from its initial announcement.
Backordered An Out Of Stock item is an item that we normally have available to ship but we are temporarily out of. We do not have a specific date when it will be coming.
Awaiting Repress Awaiting repress titles are in the process of being repressed by the label. No ETA is available at this time.
Expected On When an item is Out Of Stock and we have an estimated date when our stock should arrive, we list that date on our website in the part's description. It is not guaranteed.
Special Order A Special Order item is an item that we do not stock but can order from the manufacturer. Typical order times are located within the product description.

SKU:
TARTTA05
UPC:
TARTFMSS

The S-Series TA-0.5 belt drive turntable is available in two versions. #18395 comes equipped with a 9? bamboo tone arm. #20489 is a fully complete out of the box turntable complete with standard 9? bamboo tone arm, cartridge and built in MM phono section. Both versions feature a bamboo plinth soaked in hemp oil sealed with bees wax, leveling legs, brass pulley, bronze collar spike bearing with an ABEC7 Carbonized Ceramic Ball Bearing and a aluminum sub platter with bronze shaft.

Table Details
  • Plinth: 3 Ply Bamboo laminate 19.05mm (3/4?)
  • Motor: Single 24 Pole Synchronous AC Motor
  • Pulley: Brass Pulley
  • Speed: 33.3 & 45 rpm
  • Drive: Belt Drive
  • Platter: 3-ply Bamboo Laminate 19.05mm (3/4?)
  • Sub Platter: Aluminum Sub Platter with Steel Shaft
  • Legs: Leveling Legs
  • Bearing: Bronze Collar Bearing with ABEC7 Carbonized Ceramic Ball Bearing
  • Dimensions: H 15.5cm x W 40.9cm x L 33.3cm / 8 1/4? x 16? x 32.39?
Arm Details

The S Series 9” (222mm) arm comes pre mounted on either version of the S series turntable. The tone arm features the same handmade bamboo design, soaked in hemp and sealed in bees wax as Tri-Art's table design.

  • Material: Three Ply Bamboo Laminate 12mm
  • Settings: VTA & Azimuth Adjustments
  • Anti-Skate Adjust: Passive Anti-Skate
  • Bearing Assembly: Bronze with Brass Collar Spike and Synthetic, High Viscosity Grease Bearing
  • Arm Base: Bamboo Supports on Plyinth
  • Wiring: Cardas Wire 33 AWG Uninterrupted from Headshell Clips to Brass Female RCA with Silver Plated Cartridge Clips
  • Level: Micro Bubble Level Included
  • Arm Length: 9” / 222 mm
  • Tone Arm Mass: 10g
Cartridge Details
  • Cartridge Included: Audio-Technica 95E
  • Frequency Response: 20-20,000 HZ
  • Channel Separation: >20db at 1 Khz
  • Tracking Force: 1.5-2.5 grams
  • Load Impedance: 47,000 Ohms
  • Output: 3.5 mV (1Khz, 5cm/sec)
  • Channel Balance: within 2.0 Db
  • Stylus Type: 0.4 x 0.7 mil elliptical diamond stylus
  • Cantilever: Alloy Tube
Phono Details
  • Phono Amp: 5mv, 47ohm Cartridges
  • MM/MC: MM only
  • Bypass Switch: Phono Bypass Switch for use with an external phono amp.
