Grado Timbre Opus3 MM Cartridge (4.8mV, High Output)
Grado Timbre Opus3 MM Cartridge (4.8mV, High Output) Grado Timbre Opus3 MM Cartridge (4.8mV, High Output) Grado Timbre Opus3 MM Cartridge (4.8mV, High Output)
:

Share:

Grado Timbre Opus3 MM Cartridge (4.8mV, High Output)

$275.00



Availability: Backordered
In Stock An In Stock item is available to ship normally within 24 business hours.
Preorder A Preorder is an item that has not yet been released. Typically the label will set a projected release date (that is subject to change). If a projected release date is known, we will include this in the description in red. Other Preorders are set to release "TBA." This means that release date is yet "To Be Announced". The Preorder can be released anywhere between weeks, months or years from its initial announcement.
Backordered An Out Of Stock item is an item that we normally have available to ship but we are temporarily out of. We do not have a specific date when it will be coming.
Awaiting Repress Awaiting repress titles are in the process of being repressed by the label. No ETA is available at this time.
Expected On When an item is Out Of Stock and we have an estimated date when our stock should arrive, we list that date on our website in the part's description. It is not guaranteed.
Special Order A Special Order item is an item that we do not stock but can order from the manufacturer. Typical order times are located within the product description.
SKU:
GRATIM3OPH
UPC:
GRADOTIMOP3H

This product can only be shipped to U.S. addresses.
Retip: $180

A Grand Entrance

Bringing extreme levels of clarity over the full frequency range, the Opus3 bridges together entry-level and mid-range. The Opus3 is the easiest way to enter the family of Grado's wooden cartridges.

Bridging the Gap

The Opus3 was built specifically to bring the entry-level and the mid-range phono cartridges closer together, creating an even tighter ecosystem of cartridges. Grado worked on the Opus3 knowing they wanted to have a cost-effective wooden cartridge while at the same time taking advantage of the techniques and processes used in the higher-end models. If taking a step up in your turntable setup is on your to-do list, start here.

First of its Kind

When it comes to the Opus3, there are a few "firsts". This is the first cartridge built with a maple wood housing, as well as the first to use what Grado learned with their high-end cartridges at such an entry-level price. The housing is a new shape but still keeps the wood working in tandem with the cartridge inside. This is also the first cartridge built specifically with the Timbre Series in mind.

Extreme Precision

Grado has combined newly developed coil winding techniques with decades-old disciplines. A new two-step shielding process brings not only exact unison between the four coils but an unobstructed path for a cleaner signal. The music is allowed to travel undistorted through the coils, greatly reducing mechanical noise. There is an extreme clarity over the full frequency range, with absolutely no stridency or shrillness. Precisely hand tipped with a diamond, a great amount of care go into each cartridge Grado build.

Built from Maple

The Opus3 is nestled inside a maple housing, something a cartridge has never done before. After years of working with maple from our Heritage and Statement Series headphones, we knew it was time to bring it to a turntable. Maple produces a vibrant and luscious sound, while staying consistent and clear. Through a variation of thermal aging processes, the housing gains the ability to better dampen and control the resonant frequencies.

Hand-Built in Brooklyn with Love

Each Opus3 is hand-built by Grado's team in Brooklyn. Fine tuned for everything from entry-level turntables up to the highest-end stereo systems, the solid mass of the wood helps keep the Opus3 steady and producing the Grado signature sound. We started building cartridges on a kitchen table in 1953, and every experience since then has led to the creation of the Opus3.

Technical Specifications

Body Maple Wood
Cantilever Aluminum / Elliptical Diamond
Input Load 10k-47k ohms
Cartridge Weight 8 grams
Tracking Force 1.6-1.9 grams
Compliance 20μm/mN
Channel Seperation Average 30db - 10-30k Hz
Controlled Frequency Response 10-60 kHz
Capacitive Load Sensitivity None
Builds High Output, Low Output, Mono

High/Low Output Comparison

High Output Low Output
Output 4.8mV @5 CMV (45) 1.0mV @5 CMV (45)
Inductance 55mH 6mH
Resistance 660 ohms 70 ohms
Description

This product can only be shipped to U.S. addresses.
Retip: $180

A Grand Entrance

Bringing extreme levels of clarity over the full frequency range, the Opus3 bridges together entry-level and mid-range. The Opus3 is the easiest way to enter the family of Grado's wooden cartridges.

Bridging the Gap

The Opus3 was built specifically to bring the entry-level and the mid-range phono cartridges closer together, creating an even tighter ecosystem of cartridges. Grado worked on the Opus3 knowing they wanted to have a cost-effective wooden cartridge while at the same time taking advantage of the techniques and processes used in the higher-end models. If taking a step up in your turntable setup is on your to-do list, start here.

First of its Kind

When it comes to the Opus3, there are a few "firsts". This is the first cartridge built with a maple wood housing, as well as the first to use what Grado learned with their high-end cartridges at such an entry-level price. The housing is a new shape but still keeps the wood working in tandem with the cartridge inside. This is also the first cartridge built specifically with the Timbre Series in mind.

Extreme Precision

Grado has combined newly developed coil winding techniques with decades-old disciplines. A new two-step shielding process brings not only exact unison between the four coils but an unobstructed path for a cleaner signal. The music is allowed to travel undistorted through the coils, greatly reducing mechanical noise. There is an extreme clarity over the full frequency range, with absolutely no stridency or shrillness. Precisely hand tipped with a diamond, a great amount of care go into each cartridge Grado build.

Built from Maple

The Opus3 is nestled inside a maple housing, something a cartridge has never done before. After years of working with maple from our Heritage and Statement Series headphones, we knew it was time to bring it to a turntable. Maple produces a vibrant and luscious sound, while staying consistent and clear. Through a variation of thermal aging processes, the housing gains the ability to better dampen and control the resonant frequencies.

Hand-Built in Brooklyn with Love

Each Opus3 is hand-built by Grado's team in Brooklyn. Fine tuned for everything from entry-level turntables up to the highest-end stereo systems, the solid mass of the wood helps keep the Opus3 steady and producing the Grado signature sound. We started building cartridges on a kitchen table in 1953, and every experience since then has led to the creation of the Opus3.

Technical Specifications

Body Maple Wood
Cantilever Aluminum / Elliptical Diamond
Input Load 10k-47k ohms
Cartridge Weight 8 grams
Tracking Force 1.6-1.9 grams
Compliance 20μm/mN
Channel Seperation Average 30db - 10-30k Hz
Controlled Frequency Response 10-60 kHz
Capacitive Load Sensitivity None
Builds High Output, Low Output, Mono

High/Low Output Comparison

High Output Low Output
Output 4.8mV @5 CMV (45) 1.0mV @5 CMV (45)
Inductance 55mH 6mH
Resistance 660 ohms 70 ohms
